Clarion M508 User Manual

English
Owner’s Manual
M508
21
5. WIRE CONNECTION
Wired Remote
Black
Black
Black
OEM Steering Wheel
16-Pin Connector
Extension Lead
Yellow wire
(Memory back-up lead)
Connect directly
to battery
Red wire
(Power lead)
Accessory
12V
Blue wire
Purple/Black
Green
Green/Black
Grey
Front Right
Antenna
White
White
White
White
Front
Channel
Rear
Channel
2-Zone
Subwoofer
Grey
Black
Green
Purple
Black
Left
Left
Left
Right
Right
Right
Red
Red
Red
Red
Front Left
Rear Right
Rear Left
Grey/Black
White
White/Black
Purple
Power Antenna
Blue/White wire
(Amplier turn-on lead)
Orange/White wire
(Illumination lead)
Connect to the vessel power
supply terminal for illumination
Black wire (Ground lead)
Connect to vessel chassis ground
•
Connect to remote turn-on lead
of amplier
•
Connect it to the vessel power
supply terminal for antenna
Black
SiriusXM
Microphone


15A

Clarion M508 Specifications

General

Display Color	White
Water Resistance	IP55
Subwoofer Output	Yes
USB	Yes
AUX Input	Yes
USB Location	Rear
AUX Location	Rear
Bluetooth	Yes
SiriusXM Ready	Yes
Pandora	Yes
iHeartRadio	Yes
Type	Marine Digital Media Receiver
Display	LCD
Power Output	50 watts x 4 channels
Outputs	6-Channel RCA
