NX602

Note:

*1ConnecttotheAUXaudioinputterminalandtheiPodvideoinputterminal.(Audioconnection

isrequiredonlywhen[Analog]isselectedfortheiPodoutputsignal.SeeOwner’sManual.)

*2In certainvehicles-Volkswagen/Opel/Vauxhall-itisnecessarytoexchangetheaccessory

<<Red>>andthemainpower<<Yellow>>connection,toavoidoverloadandlossofmemory.

*3Whenthe unitis installedina 1998or laterVolkswagenmodel,makesuretointerruptthe

<<Remote>>output.

 Disconnectthe<<blue/white>>wireandinsulatethefrontendsofthiscord.Abreakdownmay

occurifthecordisnotdisconnected,orfrontendsarenotinsulated.

Installation Guide

Connecting the parking brake cord

Connect the cord to parking brake lamp ground in the meter panel.

Note:

 • Connectingtheparkingbrakecordtolampgroundallowsyoutowatchvideoimageswhen

theparkingbrakeisengaged.

 • Whentheparkingbrakecordisnotconnected,themonitorwillnotdisplayvideoimages.

Parking brake lamp

cord to battery

Parking brake

Electro-tap

Parking brake signal cord

Parking brake cord (Grass-green)

Parking brake signal cord

Stopper

Parking brake cord (Grass-green)
