Clarion ProAudio DXZ845MC User Manual

DXZ845MC 13
English
Setting the Anti Distortion Filter
The adopted “Liveliness Enhancement Filter”
and “Sound Tone Compensation” functions al-
low well-modulated realistic playback without af-
fecting the characteristics of the original sound
tone.
This unit are provided with 3 types of sound
tone effects stored in memory. Select the one
you prefer.
∗ The factory default setting is “ADF OFF”.
Each time you press the [ADF] button, the tone
effect changes in the following order:
“ADF-1” ➜ “ADF-2” ➜ “ADF-3” ➜
“ADF OFF” ...
• ADF-1 : suitable for the genuine speakers
• ADF-2 : suitable for separate speakers
• ADF-3 : suitable for coaxial speakers
• ADF OFF : no sound effect
Notes:
• The volume changes each time the ADF (Anti Dis-
tortion Filter) setting is switched. Turn down the
volume and the sub-woofer volume before per-
forming a switching operation.
• Sufficient effects cannot be obtained with some
speaker systems. In such cases, adjust the vol-
ume.
Adjusting the tone
Press the [A-M] button and select the item to
adjust. Each time you press the [A-M] button,
the item changes as following order:
● When “ADF 1, 2, 3” is set
“SW-VOL 0” ➜ “BALANCE 0” ➜ “FADER 0”
➜ Last function mode.
● When “ADF OFF” is set
“SW-VOL 0” ➜ “BASS
ÅÅ
ÅÅ
Å
GAIN
ÎÎ
ÎÎ
Î
” ➜
“TREB
ÅÅ
ÅÅ
Å
GAIN
ÎÎ
ÎÎ
Î
” ➜ “BALANCE 0” ➜
“FADER 0” ➜ Last function mode.
Note:
• As subwoofer is effective, “SW-VOL 0” can be
selected.
Adjusting the Subwoofer
∗ The factory default setting is “SW-VOL 0”
∗ This function can be adjusted only when the
subwoofer output is set to “ON”. For details on “Se-
lecting the Subwoofer”, refer to the section “Op-
erations Common to Each Mode” of each owner’s
manual.
1. Press the [A-M] button, “SW-VOL 0” appears
in the display.
Basic Operations
2. Turning the [ROTARY] knob to select from –6
to +6.
3. When the adjustment is complete, press the
[A-M] button several times until the function
mode is reached.
Adjusting the bass (Gain,
Frequency, Q-curve)
This adjustment can be performed when the
ADF (Anti Distortion Filter) is set to “ADF OFF”.
1. Press the [A-M] button and select
“ BASS
ÅÅ
ÅÅ
Å
GAIN
ÎÎ
ÎÎ
Î
”.
2. Turning the [ROTARY] knob clockwise em-
phasizes the bass; turning it counterclock-
wise attenuates the bass.
∗ The factory default setting is “BASS
ÅÅ
ÅÅ
Å
G 0
ÎÎ
ÎÎ
Î
”.
(Adjustment range: –6 to +8)
3. Press the [a] or [d] button to select
“BASS
ÅÅ
ÅÅ
Å
F 50
ÎÎ
ÎÎ
Î
”.
Tur ninng the [ROTARY] knob clockwise or
counterclockwise to select the frequency.
∗ The factory default setting is “BASS
ÅÅ
ÅÅ
Å
F
50
ÎÎ
ÎÎ
Î
”.(Adjustment 50/80/120 Hz)
4. Press the [a] or [d] button to select
“BASS
ÅÅ
ÅÅ
Å
Q 1
ÎÎ
ÎÎ
Î
”.
Tur ning the [ROTARY] knob clockwise or
counterclockwise to select the Q-curve.
∗ The factory default setting is “BASS
ÅÅ
ÅÅ
Å
Q 1
ÎÎ
ÎÎ
Î
”.
(Adjustment 1/1.25/1.5/2)
5. When the adjustment is complete, press the
[A-M] button several times until the function
mode is reached.
Adjusting the treble (Gain,
Frequency)
This adjustment can be performed when the
ADF (Anti Distortion Filter) is set to “ADF OFF”.
1. Press the [A-M] button and select
“ TREB
ÅÅ
ÅÅ
Å
GAIN
ÎÎ
ÎÎ
Î
”.
2. Turning the [ROTARY] knob clockwise em-
phasizes the treble; turning it counterclock-
wise attenuates the treble.
∗ The factory default setting is “TREB
ÅÅ
ÅÅ
Å
G 0
ÎÎ
ÎÎ
Î
”.
(Adjustment range: –6 to +6)
3. Press the [a] or [d] button to select
“TREB
ÅÅ
ÅÅ
Å
F 12k
ÎÎ
ÎÎ
Î
”.
Tur ning the [ROTARY] knob clockwise or
counterclockwise to select the frequency.
∗ The factory default setting is “TREB
ÅÅ
ÅÅ
Å
F 12k
ÎÎ
ÎÎ
Î
”.
(Adjustment 8 kHz/12 kHz)

Clarion ProAudio DXZ845MC Specifications

FM Tuner

frequency range	87.9 MHz to 107.9 MHz
usable sensitivity	9 dBf
50dB quieting sensitivity	15 dBf

AM Tuner

frequency range	530 kHz to 1710 kHz
usable sensitivity	25 µV

CD Player

frequency response	5 Hz to 20 kHz
signal to noise ratio	100 dB
dynamic range	95 dB

Audio

maximum power output	212 W (53 W ✕ 4 ch)
continuous average power output	18 W ✕ 4, into 4 Ω, 20 Hz to 20 kHz, 1%THD
line output level	1.8 V

General

power supply voltage	14.4 V DC (10.8 to 15.6 V allowable)
current consumption	Less than 15 A, 3A
speaker impedance	4 Ω (4 Ω to 8 Ω allowable)

Weight and Dimensions

weight source unit	3.52 lb. (1.6 kg)
weight remote control unit	2.82 oz. (80 g)
dimensions source unit	7" (Width) ✕ 2" (Height) ✕ 6-1/8" (Depth)
dimensions remote control unit	1-3/4" (Width) ✕ 4-5/16" (Height) ✕ 1-1/8" (Depth)
