Clarion ProAudio DXZ845MC User Manual

DXZ845MC 25
English
Setting the method for title scroll
Set how to scroll in CD-TEXT, MP3/WMA TITLE.
∗ The factory default setting is “ON”.
1. Press and hold the [T] button for 1 second or
longer to switch to the adjustment selection
display.
2. Press the [a] or [d] button to select
“AUTO SCROLL”.
3. Tu r ning the [ROTARY] knob clockwise or
counterclockwise and select “ON” or “OFF”.
● ON:
To scroll automatically.
● OFF:
To scroll just 1 time when the title was
changed or the title key was pressed.
4. Press the [T] button to return to the previous
mode.
Dimmer control
You can setting the dimmer control ON or OFF.
∗ The factory default setting is “ON”.
1. Press and hold the [T] button for 1 second or
longer to switch to the adjustment selection
display.
2. Press the [a] or [d] button to select
“DIMMER”.
3. Tu r ning the [ROTARY] knob clockwise or
counterclockwise and select “ON” or “OFF”.
4. Press the [T] button to return to the previous
mode.
Adjusting the display contrast
You can adjust the display contrast to match the
angle of installation of the unit.
∗ The factory default setting is “8”. (Adjustment level:
1 to 16)
1. Press and hold the [T] button for 1 second or
longer to switch to the adjustment selection
display.
2. Press the [a] or [d] button to select
“CONTRAST”.
3. Tu r ning the [ROTARY] knob clockwise or
counterclockwise to adjust the contrast.
4. Press the [T] button to return to the previous
mode.
Operations Common to Each Mode
Anti-theft indicator
The red Anti-theft indicator is a function for pre-
venting theft. When the DCP is removed from
the unit, this indicator blinks.
∗ The factory default setting is “OFF”.
1. Press and hold the [T] button for 1 second or
longer to switch to the adjustment selection
display.
2. Press the [a] or [d] button and select
“BLINK LED”.
3. Turning the [ROTARY] knob clockwise to set
this function “ON” or turn it counterclockwise
to switch this function “OFF”.
4. Press the [T] button to return to the previous
mode.
Setting the Subwoofer
∗ The factory default setting is “SUB-W ON”.
1. Press and hold the [T] button for 1 second or
longer to switch to the adjustment selection
display.
2. Press the [a] or [d] button and select
“SUB-WOOFER”.
3. Tur ning the [ROTARY] knob clockwise or
counterclockwise and select “ON” or “OFF”.
4. Press the [T] button to return to the previous
mode.
Setting LOW PASS FILTER
∗ The factory default setting is “THRGH”.
1. Press and hold the [T] button for 1 second or
longer to switch to the adjustment selection
display.
2. Press the [a] or [d] button to select
“SUB-W LPF”.
3. Tur ning the [ROTARY] knob clockwise or
counterclockwise to select the setting. Each
time you turning the [ROTARY] knob, the set-
ting changes in the following order:
THRGH ➜ 50Hz ➜ 80Hz ➜ 120Hz
4. Press the [T] button to return to the previous
mode.

Clarion ProAudio DXZ845MC Specifications

FM Tuner

frequency range	87.9 MHz to 107.9 MHz
usable sensitivity	9 dBf
50dB quieting sensitivity	15 dBf

AM Tuner

frequency range	530 kHz to 1710 kHz
usable sensitivity	25 µV

CD Player

frequency response	5 Hz to 20 kHz
signal to noise ratio	100 dB
dynamic range	95 dB

Audio

maximum power output	212 W (53 W ✕ 4 ch)
continuous average power output	18 W ✕ 4, into 4 Ω, 20 Hz to 20 kHz, 1%THD
line output level	1.8 V

General

power supply voltage	14.4 V DC (10.8 to 15.6 V allowable)
current consumption	Less than 15 A, 3A
speaker impedance	4 Ω (4 Ω to 8 Ω allowable)

Weight and Dimensions

weight source unit	3.52 lb. (1.6 kg)
weight remote control unit	2.82 oz. (80 g)
dimensions source unit	7" (Width) ✕ 2" (Height) ✕ 6-1/8" (Depth)
dimensions remote control unit	1-3/4" (Width) ✕ 4-5/16" (Height) ✕ 1-1/8" (Depth)
