06-12
11
Clean Track
®
16 / 18 / 18 Wash & Rinse
HANDLE SYSTEM 18
FORM NO. 56041660
Item Ref. No. Qty Description
1 7-39-00028 1 Knob-Solution Flow Module (Clean Track 18 Wash & Rinse)
2 56324272 1 Switch, Rocker (S2)
3 6 Wsh, Flt SAE SS 1/4
4 4 Scr, Pan Phil SS 1/4-20 X 2.50
5 2 Scr, Pan Phil SS 1/4-20 X 2.75
6 56009095 1 Nut, Conduit Lock 1/2-14
7# 56265056 1 Circuit Breaker W/Boot (F1 / 115V)
# 56265104 1 Circuit Breaker W/Boot (F1 / 230V)
8# 56265097 1 Switch, Rocker (S1 / 115V)
# 56393312 1 Switch, Rocker (S1 / 230V)
9# 56266020 1 Handle (115V)
# 56266135 1 Handle (230V)
10 56266043 1 Main Cable Assembly
11 56266074 1 Cord, Pigtail (Clean Track 18 Wash & Rinse)
*# 56265162 1 Cord, Power 14/3 SJT (Clean Track 16 & 18 / 115V)
*
# 56265115 1 Cord Set, 3 x 1.5 Yellow (Clean Track 16 & 18 / 230V)
12 56266089 1 Wire Assy, Handle
13 56266090 1 Wire Assy, S1_To_F1
14 56486112 1 Clamp, P
15 40147a 1 Power Cord Assy (Clean Track 18 Wash & Rinse)
16 52504a 1 Variable Flow Control (S3 / Clean Track 18 Wash & Rinse)
17
# 56183523 1 Terminal Block (230V)
18# 56209321 1 Switch, Rocker DPST (S4 / 230V)
*# 56266137 1 Wire Asm Blk 14 Awg X 9.00 (230V)
*# 56266138 1 Wire Asm Grn/Wht 14 Awg X 8.00 (230V)
*# 56266139 1 Wire Asm Blk 14 Awg X 16.00 (230V)
*# 56266140 1 Wire Asm Wht 14 Awg X 16.00 (230V)
*# 56266141 1 Wire Asm Wht 14 Awg X 10.00 (230V)
** 11145A 1 Kit, Handle Assy Hardware
# = Revised or new since last update
* = Not Shown
** = Optional, Not Included
HANDLE SYSTEM
07-10
