Clarke MIG 100E - MIG 150 TE Settings

AB C
0.8 MAX 1 6
1.0 - 1.5 MIN 2 8
1.5 - 2.0 MAX 2 8
2.0 - 3.0 MIN 3 9
>3.0 MAX 2/3 10
Workpiece
Thickness
(mm)
Welding
Position
Wire Speed
Adjustment
0.8 mm Gas Welding Wire
ALUMINIUM
Workpiece
Thickness
(mm)
Welding
Position
Wire Speed
Adjustment
Welding
Position
Wire Speed
Adjustment
0.6 mm Gas Welding Wire 0.8 mm Gas Welding Wire
AB C AB C
0.5 - 0.6 MIN 1 5 MIN 1 5
0.6 - 0.8 MAX 1 5-6 MAX 1 5
0.8 - 1.0 MIN 2 6 MIN 2 5
1.0 - 1.2 MAX 2 6 MAX 2 6
1.2 - 2.0 MIN 3 6 MAX 3 6
2.0 - 3.0 MAX 3 7 MAX 3 6
>3.0 MAX 3 7-8 MAX 3 7
STEEL
CONTROL SETTINGS - REFERENCE TABLES
B. MIG 150TE
