23
D. Trim the Welding Wire
Trim the welding wire so that it protrudes no more than 5mm from the end of the
shroud.
E. Attach the Earth Lead
Attach the earth lead to the workpiece with the earth clamp, as close to the
point of weld as possible, without it being intrusive.
Ensure there is good contact, if necessary, clean the area with a wire brush
beforehand....Remember, the contact MUST be on bare metal - thoroughly clean..
Your welder is now fully prepared for welding.
OPERATION
With the welding current set, and welding wire trimmed, set the wire feed control
to 6 , (8 for Aluminium). Plug the machine into the mains supply or switch on at the
isolator and ensuring all precautions have been taken and with the machine set
up correctly, lower the torch to the workpiece with one hand, whilst holding the
welding mask in the other.
Approach the work with the tip at an angle of approx. 45
O
and pull the torch
trigger fully. A welding current is now available at the tip and gas will be issued.
As the electrode touches the workpiece, an arc will be struck......BEFORE it is struck,
cover the face with the face mask.
Maintain a gap of approx. 5 - 7mm from the workpiece to the tip, and feed the
wire into the molten pool at a steady rate, along the line of the proposed weld.
The speed of weld will depend upon the wire speed and welding current.
NOTES:
As MIG welding is an acquired skill, it is strongly advised that, if you are not fully
familiar with this type of welding, you practise on a piece of material with the
same characteristics as that of your workpiece, until you are satisfied with the
result, and you have fine tuned your welder to produce a satisfactory weld.
One of the problems experienced with novice welders, is the welding wire sticking to the
contact tip. This is as a result of the wire feed speed being too slow. It is always better
therefore to start with too high a speed, and back off slightly, to avoid the possibility of the
wire welding itself to the tip. This is the reason position 6 is recommended for start up.
The Wire Feed control is for fine tuning the wire speed. The speed of wire delivery
will increase automatically as the current is increased from MIN to MAX, and vice
versa. Therefore, once the ideal speed is achieved, by fine tuning, it should not be
necessary to adjust this control when the welding current is changed.
Listen to the sound made. An irregular crackling sound denotes too high a wire
speed. Decrease the speed until a regular, strong buzzing sound is heard.
