SPECIFICATIONS
Please note that the details and specifications contained herein, are correct at the time of
going to print. However, CLARKE International reserve the right to change specifications at any
time without prior notice. ALWAYS CONSULT THE MACHINE’S DATA PLATE
* Duty Cycle: Determines the machine ‘down time’.
e.g. MIG100E, operating at 40 Amps - Duty Cycle - 60%. This means that in ANY 10 minute period, the
machine may operate for 6 minutes and must have a down time of 4 minutes.
PRO-90 100E 150T3E
Power Supply 230V 50Hz 1Ph 230V 50Hz 1Ph 230V 50Hz 1Ph
Fuse Rating 13Amps 13Amps 20Amps
Current Range 24-90A 30-100A 30-150A
Max. Metal Thickness (m/s) 3-4mm 4-5mm 6mm
Welding Wire Sizes 0.6-0.8mm 0.6-0.8mm 0.6-0.8mm
Duty Cycle* 8% 80A 100A 130A
60% 30A 40A 75A
100% 24A 30A 55A
Dimensions (mm) 430X250X370 430X250X370 700X320X580
Weight 24KG 25kg 32kg
Part No. 6010296 6010909 6010141
WIRING DIAGRAMS
MIG PRO-90
To Next Page
