Diode and continuity measurement
Range Resolution Accuracy Overload protection
1 mV Display approximate forward
voltage drop: 0,5~0,8 V
250 V DC or AC
1 Ω Buzzer beeps at < 70 W
Square wave output
Range Illustration
Approx. output 50 Hz square wave signal. As a simple signal
source with 47 kΩ resistance output.
Remark: No overload protection. Make sure voltage level of calibrated equipment is
less than 10 V to avoid damages to the meter.
