CleanSpace Respirators USER INSTRUCTIONS
13
The CleanSpace Respirator comes supplied with two neck
supports:
▪ PAF-1028 NECK SUPPORT SMALL
▪ PAF-1012 NECK SUPPORT MEDIUM
▪ PAF-1013 NECK SUPPORT LARGE
Select the appropriate size neck support.
The neck support has keyhole openings at each end which
snap over buttons on the Power Unit. Place the neck support
in position against the buttons and then press firmly towards
the Power Unit until the buttons engage in the keyhole
openings.
Fit a mask to the Power Unit
•
The left hand mask arm is open, whilst the right one
is closed. The figure on the right highlights the left
hand (open) mask arm.
•
Connect the left hand mask arm to the left hand
Power Unit bellow. The left hand Power Unit bellow.
is on the same side as the “POWER” button.
•
Ensure the AirClip is securely fastened as shown in Figure B below.
Figure A. Connect the left hand mask arm with the
bellow.
Figure B. Mask fastened to Power Unit. Note: connection is on
the left hand side
IMPORTANT: Ensure the mask is the right way up. The
pointed nose section of the mask must face up in the
same direction as the keypad. See Figure on the right.
Leave the other mask arm and bellow unattached until
you don the CleanSpace respirator.
Fit the harness to the mask
