CleaverBrooks FLX User Manual

750-177 8-7
Parts List, HP Steam 250 350 500 800 1100
ITEM DESCRIPTION PART # REQ PART # REQ PART # REQ PART # REQ PART # REQ
1.
Base 315-1124 1 315-1169 1 315-1180 1 315-1194 1 315-1203 1
2.
Roof 315-1215 1 315-1230 1 315-1239 1 315-1250 1 315-1260 1
3.a
Front wall w/o Hinge 315-1263 1 315-1264 1 n/a n/a n/a
3.b
Front wall w Hinge 315-1216 1 315-1229 1 315-1238 1 315-1249 1 315-1249 1
4.
Rear wall-large piece 315-1217 1 315-1228 1 315-1237 1 315-1248 1 315-1248 1
5.
Outer casing panel 315-1218 6 315-1227 6 315-1236 8 315-1247 10 315-1257 12
6.
Outer casing strips-top 315-1131 2 315-1163 2 315-1174 2 315-1188 2 315-1197 4
7.
Plate, base to wall 315-1132 4 315-1132 4 315-1132 4 315-1132 4 315-1132 4
8.
Outer casing strips corner strip 315-1219 4 315-1226 4 315-1235 4 315-1246 4 315-1246 4
9.
Burner plate Note 5 1 Note 5 1 Note 5 1 Note 5 1 Note 5 1
10.
Inner side panel Left Hand 315-1220 2 315-1225 2 315-1234 2 315-1245 2 315-1256 2
11.
Inner side panel Right Hand 315-1221 2 315-1224 2 315-1233 2 315-1244 2 315-1255 2
12.
Mounting Plate 315-1143 2 315-1143 2 315-1143 2 315-1143 2 315-1143 2
13.
Plate, Collar, Lower Outer 315-694 2 315-694 2 315-695 2 315-695 2 315-695 2
14.
Plate, Collar, Upper Outer 315-1222 2 315-1222 2 315-1222 2 315-1243 2 315-1243 2
15.
Plate, Cover, Lug, Lifting 315-1100 1 315-1100 1 315-1100 1 315-1099 1 315-1099 1
16.
Cap, sight 550-42 1 550-42 1 550-42 1 550-42 1 550-42 1
17.
Capscrew, hex hd. 3/8”-16x 3/4”lg 868-1506 28 868-1506 30 868-1506 64 868-1506 108 868-1506 144
18.
Capscrew, hex hd. 1/2”-13x 1-1/2”lg 868-102 8 868-102 8 868-102 8 868-102 8 868-102 8
19.
Capscrew, hex hd. 5/8”-11x 1-1/2”lg 868-188 8 868-188 8 868-188 8 868-188 8 868-188 8
20.
Screw, self tapping, ¼” x 1”lg 841-423 50 841-423 56 841-423 56 841-423 56 841-423 60
21.
Locknut, hex hd., 3/8”
869-510 118 869-510 130 869-510 188 869-510 252 869-510 308
22.
Nut, hex hd., ½” brass 869-27 12 869-27 12 869-27 12 869-27 12 869-27 12
23.
Nut, hex hd., ½” 869-144 24 869-144 28 869-144 28 869-144 32 869-144 32
24.
Capscrew, Hex hd ¾”-10 x 6” LG 868-600 2 868-600 2 868-600 2 868-600 2 868-600 2
25.
Washer, flat, ½” 952-286 44 952-286 48 952-286 48 952-286 52 952-286 52
26.
Washer, flat, 5/8” 952-321 8 952-321 8 952-321 8 952-321 8 952-321 8
27.
Never-Seez 797-1816 1 797-1816 1 797-1816 1 797-1816 1 797-1816 1
28.
Inner Casing Spacer Block 315-1336 8 315-1336 8 315-1336 12 315-1336 16 315-1336 20
29.
Inner Side Panel Mid Left n/a 2 n/a n/a 315-1295 2 315-1295 2
30.
Inner Side Panel Mid Right n/a 2 n/a n/a 315-1253 2 315-1253 2
31.
Inner Side Panel Mid n/a 2 n/a 315-1242 2 n/a 315-1261 2
32.
Retaining Plates, Lower, Inner, Small 315-1178 3 315-1278 3 315-1280 3 315-1280 3 315-1280 3
33.
Retaining Plates, Lower, Inner, Large 315-1158 1 315-1158 1 315-1282 1 315-1182 1 315-1182 1
34.
Plate, collar, upper, inner 315-1223 2 315-1223 2 315-1223 2 315-1254 1 315-1254 2
35.
Ring Seal, Outlet Steam #150 315-517 1 315-518 1 315-519 1 315-550 1 315-221 1
36.
Assembly, rear wall corner piece 315-1286 1 315-1287 1 315-1289 1 315-1291 1 315-1291 1
37.
Assembly, front wall corner piece 315-1285 1 315-1288 1 315-1290 1 315-1292 1 315-1292 1
38.
Gasket, Expanded PTFE 3/8” x 3/16” 32-2560 79 ft 32-2560 86 ft 32-2560 110 ft 32-2560 114ft 32-2560 168ft
39.
Handle, Flush Mount, Snap In 865-68 12 865-68 12 865-68 16 865-68 16 865-68 16
