Disassembly
Removing the MSATA Module 2 - 19
2.Disassembly
Removing the MSATA Module
1. Turn off the computer, remove the battery (page 2 - 5), and component bay cover (page 2 - 11).
2. Locate the module, it is visible at point
(Figure 15a).
3. Carefully disconnect the cable
and remove the screw from the module (Figure 15b).
4. Lift the module up and off the computer
(Figure 15b).
Figure 15
MSATA Module
Removal
a. Remove the screw.
b. Disconnect the cable and
remove the screw.
c. Lift the 3G module up off
the socket.
1
2
3
4
a.
b.
1
4
2
3
4
c.
d.

4. 3G Module
•1 Screw
