Clevo P650HS User Manual

Introduction
Specifications 1 - 3
1.Introduction
Storage
(Factory Option) Two SATA M.2 2280 SSDs supporting
RAID level 0/1
Or
(Factory Option) One PCIe Gen3 x4 M.2 2280 SSD
Two Changeable 2.5" (6cm) SATA (Serial) Hard Disk Drives
(HDDs)/SSDs (1st: 7.0mm (h) & 2nd: 7.0mm/9.5mm (h))
supporting RAID Level 0/1
Or
One changeable 2.5" (6cm) 7.0mm/9.5mm (h) SATA (Serial)
Hard Disk Drive/Solid State Drive (SSD)
Audio
High Definition Audio Compliant Interface
S/PDIF Digital Output
Two Speakers
Sound Blaster Audio
ESS™ SABRE HIFI DAC for High Resolution Headphone
Audio
Built-In Array Microphone
Note: External 5.1CH Audio Output Supported by Line-Out,
Microphone-In and Headphone & S/PDIF Out Combo Jacks
Interface
Two USB 3.1 Gen 2 Type C Ports
Three USB 3.0 (USB 3.1 Gen 1) Ports (Including one AC/DC
Powered USB port)
Two Mini DisplayPorts (1.3)
One HDMI-Out Port
One 2-In-1 Audio Jack (Headphone & S/PDIF (Optical) Out
Combo Jack)
One Microphone-In Jack
One Line-Out Jack
One RJ-45 LAN Jack
One DC-In Jack
Communication
Built-In 10/100/1000Mb Base-TX Ethernet LAN
2.0M FHD PC Camera Module
(Factory Option) M.2 3G/4G Module
WLAN/ Bluetooth M.2 Modules:
(Factory Option) Intel® Wireless-AC 8265 Wireless LAN
(802.11ac) + Bluetooth 4.1
(Factory Option) Intel® Wireless-AC 3168 Wireless LAN
(802.11ac) + Bluetooth 4.0
(Factory Option) Qualcomm® Atheros Killer™ Wireless-AC
1535 Wireless LAN (802.11ac) + Bluetooth 4.1
(Factory Option) Qualcomm® Wireless LAN (802.11ac/ad)
+ Bluetooth 4.1
Card Reader
Embedded Multi-In-1 Push-Push Card Reader
MMC (MultiMedia Card) / RS MMC
SD (Secure Digital) / Mini SD / SDHC/ SDXC
M.2 Slots
Slot 1 for Combo WLAN and Bluetooth Module
Slot 2 for SATA or PCIe Gen3 x4 SSD
Slot 3 for SATA SSD
(Factory Option) Slot 4 for 3G/4G Module
Note: (Factory Option) LTE or 802.11ad Antenna

M.2 SSD Limitation
When slot 3 has an M.2 SATA SSD in-
stalled, then slot 2 will not be available for
M.2 PCIe SSDs.
Features
Supports NVIDIA G-SYNC Technolgy in dGPU Mode
(G-SYNC is only supported if you have a G-SYNC capable
display and a GTX series video adapter)
Virtual Reality Ready
Environmental Spec
Temperature
Operating: 5°C - 35°C
Non-Operating: -20°C - 60°C
Relative Humidity
Operating: 20% - 80%
Non-Operating: 10% - 90%
Power
Embedded 4-Cell Polymer Battery Pack, 60WH
Full Range AC/DC Adapter
AC Input: 100 - 240V, 50 - 60Hz
DC Output: 19.5V, 11.8A (230W)
Dimensions & Weight
385mm (w) * 271mm (d) * 28.8mm (h)
2.65kg (Barebone with 60WH Battery)
