Clevo P775TM - External Locator - Left Side & Rear View

Introduction
1 - 6 External Locator - Left Side & Rear View
1.Introduction
External Locator - Left Side & Rear View
Figure 4
Left Side View
1. RJ-45 LAN Jack
2. USB 3.1/
Thunderbolt
Combo Port
3. USB 3.1 Port
4. USB 3.0/3.1 Port
5. Powered USB 3.1
Port
6. Multi-in-1 Card
Reader
4
6
1
3
Left
2 5
Figure 5
Rear View
1. Vent/Fan Intake
2. HDMI-Out Port
3. Mini Display Port 1
4. Mini Display Port 2
5. DC-In Jack
Rear
4
1
2 3
1
5
