Introduction
Mainboard Overview - Bottom (Connectors) 1 - 11
1.Introduction
Mainboard Overview - Bottom (Connectors)
Figure 10
Mainboard Bottom
Connectors
1. DC-In Jack
2. Thunderbolt 4 Port
3. HDMI-Out Port
4. Mini DisplayPort
1.4
5. Panel Connector
6. Audio Board
Connector
7. Fan Connector
8. Battery Cable
Connector
9. RTC Battery
Connector
11
1
2 43
5
6
7
7
8
9
