Clevo W150ERQ - Mainboard Overview - Bottom (Connectors)

Introduction
Mainboard Overview - Bottom (Connectors) 1 - 11
1.Introduction
Mainboard Overview - Bottom (Connectors)
Figure 10
Mainboard Bottom
Connectors
1. Battery
Connector
2. HDD Connector
3. RTC Cable
Connector
4. CMOS Battery
5. HDMI-Out Port
6. RJ-45 LAN Jack
7. External Monitor
Port
8. CPU Fan Cable
Connector
9. CCD Cable
Connector
10.LVDS Cable
Connector
11. DC Jack
Connector
1
2
4
5
6
7
3
8
2
9
10
11
