Clevo W230ST - Mainboard Overview - Top (Connectors)

Introduction
1 - 10 Mainboard Overview - Top (Connectors)
1.Introduction
Mainboard Overview - Top (Connectors)
Figure 9
Mainboard Top
Connectors
1. Audio Cable
Connector
2. TouchpadConnector
3. Keyboard Cable
Connector
4. Keyboard LED
Connector
5. Multi-in-1 Card Reader
6. USB 3.0 Ports
7. HDMI-Out Port
8. External Monitor Port
9. RJ-45 LAN Jack
10. Power Switch Cable
Connector
10
1
3
2
5
7
6
8
9
4
6
6
