Note that the Touchpad and
Buttons valid operational area
is that indicated within the red
dotted lines above.
Figure 2
Front View with LCD Panel Open
1. PC Camera
2. Built-In Microphone
3. *PC Camera LED
*When the PC camera is in use,
the LED will be illuminated in red.
4. LCD
5. LED Indicators
6. Power Button
7. Keyboard
8. Touchpad & Buttons
5
7
6
2
1
3
7
4
Wireless Device
Operation Aboard Aircraft
The use of any portable electronic
transmission devices aboard aircraft
is usually prohibited.
Make sure the WLAN & Bluetooth
module(s) are OFF if you are using
the computer aboard aircraft by put-
ting the system in to Airplane Mode.
8
