Clevo W230ST - Removing the 3 G Module

Disassembly
2 - 14 Removing the 3G Module
2.Disassembly
Removing the 3G Module
1. Turn off the computer, turn it over and remove the battery (page 2 - 5), and component bay cover (page 2 - 6).
2. The 3G module will be visible at point on the mainboard (Figure 10a).
3. Carefully remove the screw
and disconnect cables & (Figure 10b).
4. The 3G module (Figure 10c) will pop-up, and you can remove it from the computer (Figure 10 d).
1
2
3
4
5
1
a.
b.
5
3
5
c.
d.
4
2
Figure 10
3G Module
Removal
a. Locate the 3G module.
b. Remove the screw and
disconnect the cables.
c. The module will pop-
up.
d. Remove the 3G mod-
ule.

5. 3G Module
•1 Screw
