Clevo W230ST - Lynx 2;9

Schematic Diagrams
B - 24 Lynx 2/9
B.Schematic Diagrams
Lynx 2/9
5
5
4
4
3
3
2
2
1
1
D D
C C
B B
A A
16Mbit
ᓮ
ᓮᓮ
ᓮإ
إإ
إહ
હહ
હᦤ
ᦤᦤ
ᦤ
Share ROM
Lynx Point - M (LPC,SMBUS,SPI,C-LINK)
iTPM ENABLE/DISABLE
TPM FUNCTION:SPI_SI High Enable
NO REBOOT STRAP: HDA_SPKR High Enable
NO REBOOT STRAP
BIOS ROM
SPI_* = 1.5"~6.5"
32Mbit
ME ROM
SPI_* = 1.5"~6.5"
SMB_CLK
SMB_DATA
SPI_CS_0#
SPI_CS_1#
SPI_SI_R
SPI_SO_R
SPI_SCLK_R
CL_DATA1
CL_CLK1
CL_RST#1
DRAMRST_CNTRL
SML1_DATA
SML1_CLK
SML0_DATA
SML0_CLK
SPI_SI
SERIRQ
SPI_HOLD#_0
SPI_WP#_0
PCH_TP26
PCH_TP1
PCH_TP2
PCH_TP4
PCH_TP3
PCH_BT_EN#
PCH_GPIO74
PCH_DRQ0_N
PCH_DRQ1_N
PCH_DRQ0_N
PCH_DRQ0_N
PCH_DRQ1_N
PCH_DRQ1_N
SERIRQ
SPI_WP#_1
SPI_HOLD#_1
PCH_SPI_DQ3
SPI_CS1#
SPI_SI
SPI_WP#_0
SPI_HOLD#_0
SPI_SO
SPI_CS0#
SPI_SI
SPI_SO
SPI_WP#_1
SPI_HOLD#_1
PCH_SPI_DQ2
SPI_CS1#
SPI_CS0#
SPI_SI
SPI_SO
SPI_CS_1#
SPI_SI_R
SPI_SO_R
SPI_SCLK_R
SPI_SCLK
SPI_SCLK SPI_SCLK
SMB_CLK
SMB_DATA
PCH_GPIO74
DRAMRST_CNTRL
SML0_CLK
SML0_DATA
SML1_DATA
SML1_CLK
PCH_BT_EN#
3.3VS
3.3VS
3.3V_M 3.3V_M
VDD3
3.3V_M
SMB_CLK 9,10
SMB_DATA 9,10
CL_DATA1 31
CL_RST#1 31
CL_CLK1 31
DRAMRST_CNTRL 3,4
SML1_DATA 38
SML1_CLK 38
LPC_AD032,38
LPC_AD132,38
LPC_AD232,38
LPC_AD332,38
LPC_FRAME#32,38
SERIRQ32,38
HSPI_MSI 38
HSPI_MSO 38
HSPI_SCLK 38
HSPI_CE# 38
SMC_VGA_THERM 11,20,38
SMD_VGA_THERM 11,20,38
Title
Size Document Number Rev
Date: Sheet
of
6-71-W2300-D03
3.0
[23] Lynx 2/9-LPC/SPI/LPC/SMB
Custom
23 51Tuesday, July 09, 2013
ᙔ!Ϻ!ႝ!တ!!DMFWP!DP/
Title
Size Document Number Rev
Date: Sheet
of
6-71-W2300-D03
3.0
[23] Lynx 2/9-LPC/SPI/LPC/SMB
Custom
23 51Tuesday, July 09, 2013
ᙔ!Ϻ!ႝ!တ!!DMFWP!DP/
Title
Size Document Number Rev
Date: Sheet
of
6-71-W2300-D03
3.0
[23] Lynx 2/9-LPC/SPI/LPC/SMB
Custom
23 51Tuesday, July 09, 2013
ᙔ!Ϻ!ႝ!တ!!DMFWP!DP/
R119 33_04
R569
3.3K_1%_04
T125
R521 *0_04
R529 *2.2K_04
R613
3.3K_1%_04
R586 *1K_04
R123 *2.2K_04
R505 2.2K_04
R196 10K_04
C571
0.1u_16V_Y5V_04
R50 10K_04
R504 *0_04
R83 2.2K_04
R24 *10K_04
R74 10K_04
R614 33_04
R121 0_04
U28
AMIC A25LQ32A
PCB Footprint = M-SOP8B
CE#
1
SO
2
WP#
3
VSS
4
SI
5
SCK
6
HOLD#
7
VDD
8
R138 20_1%_04
R85 2.2K_04
R141 20_1%_04
T124
PCH LYNX POINT SUPER SKU ES1
SMBus
C-Link
Thermal
SPI
LPC
3 OF 11
U27D
SML1ALERT#/PCHHOT#/GPIO74
H6
SPI_IO3
AJ2
SPI_MISO
AH3
SPI_IO2
AJ4
SPI_MOSI
AH1
SPI_CS2#
AJ10
SPI_CS1#
AL7
SPI_CS0#
AJ7
SPI_CLK
AJ11
LDRQ1#/GPIO23
G20
SERIRQ
AL11
LDRQ0#
D21
LFRAME#
B21
LAD_3
C18
LAD_2
A18
LAD_1
C20
LAD_0
A20
TD_IREF
AY43
CL_DATA
AF10
CL_RST#
AF7
CL_CLK
AF11
SML1DATA/GPIO75
N11
SML1CLK/GPIO58
K6
SML0DATA
R7
SML0CLK
U8
SML0ALERT#/GPIO60
N8
SMBDATA
U11
SMBCLK
R10
SMBALERT#/GPIO11
N7
TP2
BC45
TP4
BE43
TP1
BA45
TP3
BE44
R588 0_04
R530 *2.2K_04
R637 8.2K_1%_04
R118 33_04
R140 0_04
T123
R120 0_04
R583 33_04
R71 1K_04
R553
3.3K_1%_04
R522 2.2K_04
R36 *10K_04
R584
3.3K_1%_04
T122
U25
AMIC A25LQ16
PCB Footprint = M-SOP8B
CE#
1
SO
2
WP#
3
VSS
4
SI
5
SCK
6
HOLD#
7
VDD
8
R117 33_04
R122 33_04
R37 *10K_04
C595
0.1u_16V_Y5V_04
R587 33_04
R23 *10K_04
Sheet 23 of 51
Lynx 2/9
