Clevo W230ST - Removing the Battery

Disassembly
Removing the Battery 2 - 5
2.Disassembly
Removing the Battery
If you are confident in undertaking upgrade procedures yourself, for safety reasons it is best to remove the battery.
1. Turn the computer off, and turn it over.
2. Slide the latch in the direction of the arrow.
3. Slide the latch in the direction of the arrow.
4. Slide the battery (Figure b) out of the battery bay.

3. Battery
1
2
3
Figure 1
Battery Removal
a. Slide the latch in the
direction of the arrow.
and slide the latch in
the direction of the arrow.
b. Slide the battery out of
the bay as indicated.
1
2
a.
3
2
1
b.
