2 - 6 Removing the Hard Disk Drive
2.Disassembly
Removing the Hard Disk Drive
The hard disk drive is mounted in a removable case and can be taken out to accommodate other 2.5" SATA hard disk
drives with a height of 9.5mm or 7mm (h). Follow your operating system’s installation instructions, and install all nec-
essary drivers and utilities (as outlined in Chapter 4 of the User’s Manual) when setting up a new hard disk.
Hard Disk Upgrade Process
1. Turn off the computer, and turn it over and remove the battery (page 2 - 5).
2. Locate the Hard disk bay cover and remove screw - .
3. Lift and pull the bay cover in the direction of the arrow and . Remove the bay cover .
Figure 2
HDD Assembly
Removal
a. Remove the screws.
b. Remove the cover.

6. Hard Disk Bay Cov-
er
•1 Screws
1
3
4
5
6
a.
b.
1
6
3
2
4
4
5
