Disassembly
Removing the Hard Disk Drive 2 - 7
2.Disassembly
4. Grip the tab and slide the hard disk in the direction of arrow (Figure 3e).
5. Lift the hard disk assembly out of the computer.
6. Remove screws
- .
7. Separate the hard disk and hard disk mylar
.
8. Reverse the process to install a new hard disk(s).
7

11. Hard Disks
12. Hard Disk Mylar
•2 Screws
Figure 3
HDD Assembly
Removal (cont’d.)
c. Slide the hard disk as-
sembly out.
d. Lift the hard disk assem-
bly out off the computer.
e. Remove the screws to
release the hard disk
from the mylar.
8
9
10
11
12
9
d.
c.
8
e.
7
12
11
10
