Clevo W230ST User Manual

21
English
Specifications
Processor Options
Intel® Core™ i7 Processor
i7-3612QM (2.10GHz)
6MB L3 Cache, 22nm, DDR3-1600MHz,
TDP 35W
i7-3540M (3.0GHz), i7-3520M (2.9GHz)
4MB L3 Cache, 22nm, DDR3-1600MHz,
TDP 35W
Intel® Core™ i5 Processor
i5-3380M (2.90GHz), i5-3360M (2.80GHz),
i5-3340M (2.70GHz), i5-3320M (2.60GHz),
i5-3230M (2.60GHz), i5-3210M (2.50GHz)
3MB L3 Cache, 22nm, DDR3-1600MHz,
TDP 35W

Latest Specification Information
The specifications listed in this here
are correct at the time of going to
press. Certain items (particularly pro-
cessor types/speeds) may be
changed, delayed or updated due to
the manufacturer's release sched-
ule. Check with your service center
for details.
Intel® Core™ i3 Processor
i3-3130M (2.60GHz), i3-3120M (2.50GHz),
i3-3110M (2.40GHz)
3MB L3 Cache, 22nm, DDR3-1600MHz,
TDP 35W
Intel® Pentium® Processor
2030M (2.50GHz), 2020M (2.40GHz)
2MB L3 Cache, 22nm, DDR3-1333MHz,
TDP 35W
Core Logic
Intel® HM76 Chipset
BIOS
48Mb SPI Flash ROM
AMI BIOS
Memory
Two 204 Pin SO-DIMM Sockets Supporting
DDR3 1333/1600MHz Memory
Memory Expandable up to 16GB
(The real memory operating frequency
depends on the FSB of the processor.)
Storage
(Factory Option) One Changeable
12.7mm(h) Super Multi Optical Device Drive
One Changeable 2.5" 9.5mm (h) SATA
HDD
(Factory Option) One mSATA Solid State
Drive (SSD)
LCD
15.6" (39.62cm) HD / FHD
Audio
High Definition Audio Compliant Interface
2 * Built-In Speakers
Built-In Microphone
Sound Blaster ™ Cinema
Security
Security (Kensington® Type) Lock Slot
BIOS Password
Keyboard
Full-size “WinKey” keyboard (with numeric
keypad)
Pointing Device
Built-in Touchpad
Interface
Two USB 2.0 Ports
Two USB 3.0 Ports
One eSATA Port (USB 3.0 Combo)
One HDMI-Out Port
One External Monitor Port
One Headphone-Out Jack
One Microphone-In Jack
One RJ-45 LAN Jack
One DC-in Jack
