ClimateMaster Tranquility TCH 015 User Manual

climatemaster.com
41
Tranquility
®
Compact (TC) Series
Rev.: July 7, 2020
THE SMART SOLUTION FOR ENERGY EFFICIENCY
Blower Performance Data – TC015
Rated
CFM
Min CFM
Motor
Type
Motor Speed
Setting
External Static Pressure (in. wg)
0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1.0
525 375 PSC
Low CFM 503 490 479 439
Medium CFM 595 575 562 510 451
High CFM 581 510 386
525 375
PSC -
High
Static
Low CFM 462 456 443 425 385
Medium CFM 546 539 531 513 481 414
High CFM 547 426
525 375
ECM -
Constant
Torque
1
RPM 655 614 701 770 851 937
Power (W) 67 55 62 68 75 82
CFM 648 588 542 493 441 378
2
RPM 655 720 799 863 946 1021 1078
Power (W) 67 74 81 87 95 102 108
CFM 648 608 557 514 460 402 354
3
RPM 687 744 822 883 950 1032 1098 1150
Power (W) 79 86 94 101 107 117 124 130
CFM 695 659 611 570 526 475 422 377
4
RPM 716 771 844 906 965 1037 1110 1170 1219
Power (W) 92 98 107 114 121 129 138 145 151
CFM 737 705 661 622 582 534 482 438 396
5
RPM 763 790 851 924 978 1039 1113 1175 1233 1281
Power (W) 106 110 117 126 133 141 151 159 165 172
CFM 745 745 708 662 626 585 535 488 444 402
525 375
ECM -
Constant
Volume
Minimum CFM
RPM 617 741 848 945 1028 1103 1171
Power (W) 36 52 68 84 99 114 129
CFM 375 375 375 375 375 375 375
Default CFM
RPM 661 767 859 944 1028 1107 1179 1247
Power (W) 55 74 90 108 127 147 166 186
CFM 525 525 525 525 525 525 525 525
Maximum CFM
RPM 586 695 795 882 963 1038 1111 1180 1248 1312
Power (W) 54 73 93 112 132 152 173 194 216 238
CFM 625 625 625 625 625 625 625 625 625 625
See ECM control section for details on setting airow.
Airow is controlled within 5% up to the Max ESP shown with wet coil.
Do not select Dehumidication mode if HP CFM is on setting 1.
ClimaDry is factory wired to operate in stage 2 airow.
Black areas denote ESP where operation is not recommended.
PSC: Units factory shipped on medium speed. Other speeds require eld selection.
CT ECM: Units factory shipped on Speed Tap 2 for Fan-Only and Speed Tap 3 for Heating/Cooling.
All airow is rated and shown above at the lower voltage if unit is dual voltage rated, e.g. 208V for 208-230V units.
Only two speed PSC fan (H & M) available on 575V units.
Performance stated is at the rated power supply. Performance may vary as the power supply varies from the rated.
All data is shown wet coil with clean 1” lter.
All data is ran at 80 °F DB and 67 °F WB.
CFM Tolerance is 7%.
RPM/Watt Tolerance 10%.
