CLIVET CKN-XHE2i 7.1 User Manual

Error code：
Exception Code)
01
Illegal function code
Unsupported function code.
02
illegal data address
The address that is sent when query or set, undefined in the online
controller.
03
illegal data value
The parameters set are illegal, beyond the reasonable range or not
the valid parameter for current state of the wired controller.
Customer's BMS registers
Register
number
Register content
Note
0
Mode setting
8=OFF; 0=Stanby; 1=Cooling mode;
2=Heating mode
1
Temperature setpoint
16°C -- 28°C
2
Ur% setpoint
0% -- 100%
3
Constant airflow setpoint
set [m3/h]
4
Enable Auto Temperature
0=OFF; 1=ON
5
Enable ECO Mode
0=OFF; 1=ON
6
Air quality setpoint
set [ppm]
7
void
8
void
9
void
10
void
Status
Register
number
Register content
Note
200
Host address
-
201
PCB swithches setting
-
202
Encoder setting
7 = size 7.1; 11 = size 10.1; 18 = size 14.2
203
Operation mode
8=OFF; 0=Stanby; 1=Cooling mode;
2=Heating mode
204
HMI visualization
1 = ON
0 = OFF
BIT0 = Unit running
BIT1 = Compressor 1 running
BIT2 = Compressor 2 running
BIT3 = Electric air heater
BIT4 = Gas Burner or Water coil
BIT5 = Defrost Logo
BIT6 = Indoor fan state
BIT7 = Humidifier state
BIT8 = ECO running
BIT9 = Fault state
205
Current compressor
Current [A] Compressor A
37

CLIVET CKN-XHE2i 7.1 Specifications

General

Brand	CLIVET
Model	CKN-XHE2i 7.1
Category	Heat Pump
Language	English
