206
Current compressor
Current [A] Compressor B
207
Frequency compressor
Frequency [Hz] Compressor A
208
Frequency compressor
Frequency [Hz] Compressor B
209
EXV step
step
210
Outdoor fan speed
RPM
211
Supply fan output
%
212
Airflow
2000~2000 m
3
/h
213
Exhaust fan output
%
214
Damper output
%
215
Fault code
See below
216
Ai setpoint
0 ~ 65535 m
3
/h
217
T1
-25 °C ~ 70 °C
218
Tc
-25 °C ~ 70 °C
219
T2
-25 °C ~ 70 °C
220
T3
-25 °C ~ 70 °C
221
T4
-25 °C ~ 70 °C
222
TP1
-25 °C ~ 70 °C
223
TP2
-25 °C ~ 70 °C
224
TF1
0 °C ~ 140 °C
225
TF2
0 °C ~ 140 °C
226
T2B
-25 °C ~ 7 0°C
227
Tw
-25 °C ~ 70 °C
228
Pfin
0 Pa ~ 2000 Pa
229
Pfout
0 Pa ~ 2000 Pa
230
URin
0% ~ 100%
231
URout
0% ~ 100%
232
CO2 concentration
0 ppm ~ 2000 ppm
233
Exhaust fan output
%
234
Auxiliary heating source output
%
235
Humidifier output
%
236
Factory test mode output
step
In BMS reading, register 215 displays one of the following "Fault codes" in hexadecimal format (hex),
considering only the LOW BYTE.
Consider only the last two alphanumeric digits of the code.
38
