M07Z40M15-02 CSRN-XHE2 FFA 12.2-24.4 9
7
6
8
2
3
4
1
5
1 Positioning on concrete oor 5 Positioning on steel structure
2 2 cm thick neoprene strips 6 antivibration mounts
3 concrete oor 7 steel structure
4 insulation 8 steel structure
3.4 Condensate water
When a heat pump is running it produces a considerable amount of water due to the defrosting cycles of the external coil.
The condensate must be disposed in order to avoid damages to people and things.
3.5 Conguration CCFFA
3.6 Gas heating module - Electronic lters
For details see:
10 Accessoriesp.37
