DIMENSIONES
9 - INFORMA
TIONS TECHNIQUES
(1) ENTREE EAU ECHANGEUR E
UROKONUS 3/4
(2) SORTIE EAU ECHA
NGEUR EUROKONUS 3/4
(3) TUYAU EVACUAT
IONS DES CONDENSATS Ø 14 MM
TAILLES
3
5
11
15 17
A
mm 737
937
1137
1337
B
mm
131 131 131 131
C
mm
579 579 579 579
Poids net
kg
17 20 23 26
1537
131
579
29
Version à encastrer - 2 tubes
TAILLES
3
5
11
15 17
A
mm 527
727
927
1127
B
mm
126 126 126 126
C
mm
579 579 579 579
Poids net
kg 9
12
15
18
1327
126
579
21
Version apparente - 2
tubes
A
B
1
2
3
C
1
2
3
A
B
C
126
125
127
