5 - COLLEGAMENTI ELETTRICI
5.8 MINIRETE - MAX 9 ELFORoom
2
*
Resistenza terminazione rete 120
Ω
- a cura cliente
5.9 ELFOSystem GAIA Edition
1. Bus
RS485
2. ELFOControl
Home
3. GAIA
4. ELFOFRESH
2
5.
zona con 2 ELFOROOM
2
con tastiera
e termostato HID-Ti2 che
comanda entrambi i terminali
6.
zona con 1 ELFOROOM
2
con tastiera
e termostato HID-Ti2 che
comanda il terminale
7. ELFOROOM
2
con tastiera e termostato HID-T3 che comanda
entrambi i terminali
8. ELFOROOM
2
con termostato a bordo
19
18
20
