CLIVET WSAN-XPR Series User Manual

M0G940E8-00 04/07/08 pag 50
DIMENSIONS
SIZE 21
W1
W4
W2
"G"
W3
1
1
2
3
3
4
5
6
7
7
8
8
9
10
11
12
12
300
336
800
157 510 133
336
71
122
M N
P
O
(13)
500
(13)
150
(13)
100
65
117
50
98
150
360
930
The units require minimum clearances for operation and maintenance. The following sketch describes the minimum clearances to be considered. In the event of multiple units, the
functional clearances must be doubled.
Size 21
M
mm 349
N
mm 161
O
mm 176
P
mm 160
Length mm 800
Depth mm 300
Height mm 930
W1
kg 15
W2
kg 32
W3
kg 14
W4
kg 28
Operating weight kg 89
Shipping weight kg 91
(1) COMPRESSOR
(2) EXTERNAL EXCHANGER
(3) INTERNAL EXCHANGER
(4) ELECTRICAL PANEL
(5) WATER INLET 1" GAS
(6) WATER OUTLET 1" GAS
(7) HELICAL FANS
(8) PUMP
(9) WATER SIDE SAFETY VALVE
(10) POWER INPUT
(11) EXPANSION VESSEL
(12) CONDENSATE DISCHARGE
(13) CLEARANCE ACCESS RECOMMENDED
(G) BARYCENTRE
