Cloud Z4MK4 User Manual

Z4-8MK4 Installation and User Guide v1.2 11
However, the wiring method shown below will work in a large
number of cases:
1
2
3
Unbalanced
inputs
LEFT
RIGHT
+
+
SCN
SCN
+
+
SCN
SCN
LEFT
RIGHT
pin 1 ground
pin 2 hot
pin 3 cold
Balanced outputs (XLRs):
1
2
3
Balanced sources:
Source equipment with balanced outputs may be connected
directly to Line Inputs 3, 4 5 or 6. Use good quality twin-
and-screen cable and connect to the mating screw-terminal
connectors provided as shown below:
PIN CONNECTION
1 Screen
2 Signal ‘-’ (cold)
3 Signal ‘+’ (hot)
If it is necessary to connect an item of source equipment with
an unbalanced output to Line Inputs 3 to 6, connect the signal
to Pin 3 (“hot”) and Pin 1 (screen), as shown below:
31
+
+
2
Z8MK4/Z4MK4 Balanced input:
pin 1 ground
pin 2 cold
pin 3 hot
SCN
SCN
Unbalanced Output
(e
.g., phono)
Mono and stereo sources:
The Z8MK4 and Z4MK4 are mono mixers; the stereo line
inputs are summed internally to mono. Stereo sources should
be connected in a normal stereo conguration, using both L
and R inputs. If connecting a mono source with only a single
output, it may be connected to either the left or the right
input.
Zone outputs
Connect the inputs of the power ampliers feeding the
loudspeakers for each zone to the OUTPUT connectors
for Zones 1 to 8*. Note that the zone outputs are all mono.
The outputs are balanced and will drive input impedances
down to 600 ohms. Nominal output level is 0 dBu (775 mV).
The output is designed to drive professional/industrial power
ampliers with balanced inputs (typically on XLRs). In this
case, wire as the diagram below. Note that the screen can
be left unconnected at the source end if earth loops are a
problem.
1
3
+
-
+
-
SCN
pin1ground
pin2hot
pin3cold
Balanced inputs (XLRs):
12
3
2
SCSCN
Z4
MK4/Z8MK4 Balanced output:
pin 1 gr
ound
pin 2 cold
pin 3 hot
The scr
een connection at the
zone end ma
y be omitted if it
helps r
educe earth loops
*ZONE 1 to 4 only on Z4MK4.
Ampliers with unbalanced inputs:
If audio ampliers with only unbalanced inputs are being used
(e.g., hi- ampliers), the following wiring should be adopted:
1
3
+
+
2
SCSCN
Z8
MK4
/Z4
MK4
Balanced output:
pin 1 ground
pin 2 cold
pin 3 hot
When using single-core cable,
don’t connect ‘cold’ at the
Z8MK4/Z4MK4
Unbalanced input (e.g. phono)
1
3
+
+
-
2
SCSCN
Z8MK4/Z4MK4 Balanced output:
pin 1 ground
pin 2 cold
pin 3 hot
Unbalanced input (e.g., phono)
When using twin-and-screen
cable, don’t connect the screen
at the amplifier end.
-
