Z4-8MK4 Installation and User Guide v1.2 27
FRONT OF UNIT
MOTHERBOARD (at bottom of chassis)
ZONE SUB-CARDS
* Z8
MK4 ONLY
ZONE 8*
ZONE 1
ZONE 2
ZONE 3
ZONE 4
ZONE 5*
ZONE 6*
ZONE 7*
SW1 SW3
SW2
Motherboard jumper locations
SOCKET FOR
OPTIONAL EQ CARD
J8 J1J4J5J2J6
(COMPONENT SIDE)
KEY:
Jumper with two possible positions; black
square indicates factory default setting.
J3 J7
RJ45
FACILITY PORT
REMOTE SOURCE +
LEVEL
ZONE OUTPUT
Zone sub-card jumper locations
