C.M.C. n.v. - Airmaster S1 installation guide – V1.2 – MANY0402A.00
Connector X04: digital inputs
Connector type: 9-pole mini Combicon with 3.81mm (0.15”) pitch
Pin Name Function
1 C+ Contact input common
2 C1 Contact input 1
3 C2 Contact input 2
4 C3 Contact input 3
5 C4 Contact input 4
6 C5 Contact input 5
7 C6 Contact input 6
8 C7 Contact input 7
9 C8 Contact input 8 (PTC)
Cable harness plug: Phoenix Contact type MC 1,5/9-ST-3,81 or compatible
Connec X05: g inp
Con ector type min 81mm (0.15
Pin Name Function
tor analo uts
n : 6-pole i Combicon with 3. ”) pitch
1 C-ANA1 Common of analog input 1
2 ANA1 Analog input 1
3 C-ANA2 Common of analog input 2
4 ANA2 Analog input 2
5 C-ANA3 Common of analog input 3
6 ANA3 Analog input 3
Connector X06: Analog output (optional)
Con ector type min 08mm (0.2”)
n
Cable harness plug: Phoenix Contact type MC 1,5/6-ST-3,81 or compatible
n : 2-pole i Combicon with 5. pitch.
Pin Name Functio
1 AGND Analog output
2 ANA-OUT output Analog
Cable harness plug: Phoenix Contact type MC 1,5/2-ST-5,08 or compatible.
