C.M.C. n.v. - Airmaster S1 installation guide – V1.2 – MANY0402A.00
3. Technical specifications
3.1 General technical data
Display Backlit LCD symbolic/numeric
Indicators 2, LED
Buttons 7, tactile response
Processor 16bit ST ST10R272
Flash EPROM 256 Kbytes (max.)
Non Volatile RAM 128 Kbytes (max.)
A to D Resolution 10bit (1/1024)
D to A Resolution 10bit (1/1024)
Supply input 24Vac (±20%) 24VA
Analog Inputs 3 standard
Digital Inputs 8 standard
Analog Outputs 1 optional
Relay Outputs 4 standard 6 maximum
(consult CMC for combination availability)
Construction Stainless steel front plate, steel anti-corrosion coated rear enclosure
Mounting 134mm x 84mm rectangle panel aperture, up to 2.5mm plate
Dimensions 144mm x 96mm x 62,8mm
Connections PCB mounted, Phoenix compatible
Conformity
US
C
3.2 Temperature range
Operating temperature 0°C to +55°C
Storage temperature -25°C to +75°C
Relative humidity at 40°C (non
condensing)
<95%
According to:
Operating tests at -10°C and +65°C
IEC 68-2-2 B Dry heat, 4 days
IEC 68-2-14 Nb Cyclic, 6hrs/cycle, 5 days
IEC 68-2-3 Ca Damp heat steady, 40°C, tbd R.H., 10 days
IEC 68-2-30 Db Damp heat cyclic, +50°C, variant 1, 2 cycles
IEC 68-2-1 A Cold, 4 days
Storage tests at -25°C and +75°C
IEC 68-2-1 A Cold 6 days
IEC 68-2-14 Na Change of temperature, 3hrs/temp, 2 cycles
IEC 68-2-2 B Dry heat 6 days
Page 7 of 35
