C.M.C. n.v. - Airmaster S1 installation guide – V1.2 – MANY0402A.00

2. Models

2.1 Basic versions

There are 2 basic versions available of the Airmaster S1. The following table indicates

the differences. The analog conditioning modules (see further) must be added to the

basic version.

4-20mA

4 x

Relay

8 x

Digital

3 x

Analogue

RS485(1)

RS485(2)

Communications

Inputs

Outputs

S1 - 10

S1 - 20

6 x

Relay

Model Reference Number: S1-xx-3yy

xx = configuration option; 10 or 20

yy = ACM selection

for example S1-10-350 =

AI1 = (3) 4-20mA (fixed)

AI2 = (5) KTY temperature

AI3 = (0) no ACM fitted

Page 5 of 35
