CMC Airmaster S1 - RS485-1 Connector (X07); RS485-2 Optional Connector (X08)

C.M.C. n.v. - Airmaster S1 installation guide – V1.2 – MANY0402A.00
Connectors X07: RS485-1
Connector type: 2-pole mini Combicon with 3.81mm (0.15”) pitch.
Pin Name Function
1 L1+ RS485 L1+
2 L2- RS485 L2-
Cab harness : Phoenix Contact t ST-3,81 or compatible
Connector X08: RS485-2 (optional)
Connector type: 2-pole mini Combicon with 3.81mm (0.15”) pitch.
le plug ype MC 1,5/2-
Pin Name Function
1 L1+ RS485 L1+
2 L2- RS485 L2-
Cable harness plug: Phoenix Contact type MC 1,5/2-ST-3,81 or compatible.
