C.M.C. n.v. - Airmaster S1 installation guide – V1.2 – MANY0402A.00
10. Adjusting
The only possible adjustment is the contrast of the display. In the factory this is already
adjusted to its best position. When another contrast is necessary the 200 degrees trim
potentiometer can be used.
From the display side, the trim potentiometer is located on the right side of the S1.
No high pushing pressure is allowed on the trim
potentiometer, otherwise damage could occur. If operator
feels that the trim potentiometer is at one of its ends, do
not try to move it further, otherwise damage will occur.
1. Trouble shouting
he software has many diagnostic capabilities. These will not be explained in this
roblem with a controller under warranty please follow the procedure,
50
45
135
50
1
T
document. Please refer to the “Airmaster S1 software specification” for more
information.
case of a pIn
which can be asked at simple request. Try to add as much information as possible
regarding the fault and the circumstances of occurrence.
Page 24 of 35
