CMC Airmaster S1 - Power Supply Connector (X01); Optional Relay Connectors (X02); Relay Connectors (X03)

C.M.C. n.v. - Airmaster S1 installation guide – V1.2 – MANY0402A.00
Page 30 of 35
Connector X01: Supply
Connector type: 2-pole Combicon with 5.08mm (0.20”) pitch.
Pin Name Function
1 SUPPLY Supply input: AC
2 SUPPLY Supply input: AC
Cable harness plug: Phoenix Contact type MSTB2,5/2-ST-5,08 or compatible.
Connector X02: relays (optional)
Connector type: 4-pole Combicon with 5.08mm (0.20”) pitch
Pin Name Function Comment
1 NO-R5 Relay 5 normal open (Optional VDR)
2 C-R5 Relay 5 common (Optional VDR)
3 NO-R6 Relay 6 normal open (Optional VDR)
4 C-R6 Relay 6 common (Optional VDR)
Cable harness plug: Phoenix Contact type MSTB2,5/4-ST-5,08 or compatible
s
Connector type: 6-pole Combicon with 5.08mm (0.20”) pitch
Pin Name Function Comment
Connector X03: relay
1 C-R123 Relay 1,2,3 common With VDR
300VAC/385VDC; I<12A
2 NO-R1 Relay 1 normal open With VDR
300VAC/385VDC
3 NO-R2 Relay 2 normal open With VDR
300VAC/385VDC
4 NO-R3 Relay 3 normal open With VDR
300VAC/385VDC
5 NO-R4 Relay 4 normal open With VDR
300VAC/385VDC
6 C-R4 Relay 4 common With VDR
300VAC/385VDC
Cable harness plug: Phoenix Contact type MSTB2,5/6-ST-5,08 or compatible
