CMC ARIZONA VORTEX KIT - VORTEX ASSEMBLY; Head Assembly (Tripod Construction); Easel-Leg Tripod Assembly

VORTEX ASSEMBLY
The Vortex is designed to enable construc-
tion and adjustment of multiple congura-
tions. This diagram shows the assembly of
an Easel-Leg Tripod.
Outer Legs
Inner Leg
Inner Leg
Outer Legs
ARIZONA VORTEX
USER’S GUIDE
®
EXPERT USE ONLY
A
B
B
C
C
The A-Frame Head and Gin
Pole Head pin together to
construct a tripod.
| ARIZONA VORTEX KIT USER MANUAL8
