EVAC-500 Voice Alarm & Evacuation System Operation Manual
37 / 42
"All zone" means that once the fire alarm is input from the "Trigger Inputs" of the host or the extended host, wait for
" " to set the delay time, output the EVAC voice information to all the partitions of the system,
and output the EVAC information parameters The configuration of the corresponding contact is determined by the
following figure:
Contact set interface
"1" -> select the host ID number;
"2" -> set the host corresponding to the contacts;
"3" -> set the host corresponding to the contact type of voice playback and tracks:
(2)“Specify zone” Represents once from the host or extended host “Trigger Inputs” After entering the fire alarm, wait
“ ” After setting the delay time, output the EVAC voice information
“ ” The section listed in the list "users can click the button
in the pink box on the right to set the output partition", and the EVAC information parameters of the output are
determined by the "contact setting interface" above.
(3)“Neighboring mode” Once the "Trigger Inputs" from the host or extended host enter the fire alarm signal, wait
“ ” After setting the delay time, output the EVAC voice information to the corresponding partition
of the current contact, and Play the Play mode in the right image：play time “Specify the time to play” repeat
time“Specifies the number of times to play” and “ ”up“1”down“2”play ALERT
message，repeat and repeat till fire alarm message.
(3) "Specify zone" means to wait for " " to set the delay time after the fire signal is input from the
"Trigger Inputs" of the host or extension host, the EVAC voice message is output to the "listed" You can click on the right
side of the pink box button to set the output partition ", the output of the EVAC information parameters from the figure"
contact settings interface "decision.
(4) "Neighboring mode" means that once the fire alarm is input from the "Trigger Inputs" of the host or extension host,
