Preparing for the road
26www.coachman.co.uk
Owners handbook 2022
Coachman Caravan Company Limited, Amsterdam Road, Sutton Fields Industrial Estate, Hull, HU7 0XF
Friction Pads Replacement
• Unscrew the 2 screws which are under
the red rubber soft dock by using the
special tool. (Fig. 5)
• Remove screw from back plate.
(Fig. 6)
• Remove friction pads. (Fig. 7)
Loading capacity
The AKS 3004 can tow vehicles up to
gross weight of 3000kg and a maximum
nose weight of 100kg.
Uncoupling
Lower the jockey wheel to the ground.
Disconnect the breakaway cable
and plugs.
Release stabilising lever and lift the
coupling handle whilst winding.
Lift the coupling head clear of the towball.
Friction Pads are in good order
Friction Pads worn out & need
replacing
Fig.5
Fig.6
Fig.7
