Connecting services - Electricity
48www.coachman.co.uk
Owners handbook 2022
Coachman Caravan Company Limited, Amsterdam Road, Sutton Fields Industrial Estate, Hull, HU7 0XF
EARTH
BLACK
RED
GREEN & YELLOW
VIEW OF
TERMINALS
VIEW OF
SOCKET TUBES
VIEW OF
TERMINALS
VIEW OF
PINS
EARTH
NEUTRAL
GREEN & YELLOW
BROWN
BLUE
FLEXIBLE WIRING FIXED WIRING
LIVE BROWN
NEUTRAL BLUE
GREEN & YELLOW
EARTH
LIVE
NEUTRAL
EARTH
BROWN
BLUE
GREEN & YELLOW
EARTH
BLACK
RED
GREEN & YELLOW
VIEW OF
TERMINALS
VIEW OF
SOCKET TUBES
VIEW OF
TERMINALS
VIEW OF
PINS
EARTH
NEUTRAL
GREEN & YELLOW
BROWN
BLUE
FLEXIBLE WIRING FIXED WIRING
LIVE BROWN
NEUTRAL BLUE
GREEN & YELLOW
EARTH
LIVE
NEUTRAL
EARTH
BROWN
BLUE
GREEN & YELLOW
FLEXIBLE 3 CORE CABLE 2.5mm
2
WIRING OF CONNECTING CABLE AND CARAVAN MAINS INLET
IT IS ESSENTIAL THAT CONNECTIONS ARE MADE EXACTLY AS
SHOWN, IF TERMINAL MARKINGS ARE NOT IN ACCORDANCE WITH
THE ABOVE DIAGRAM THEY MUST BE IGNORED.
The following items need to be added
together if used simultaneously.
230V mains equipment typical
consumption figures:
Fridge 0.80 amps
Charger 0.80 amps
Water heater 3.7 amps
Blown air heaters (Elec) 8.00 amps
Colour TV 2.50 amps
Microwave 6.00 amps
Air conditioning (Elec) 4.00 amps
Kettle 1.5 KW 6.5 amps
3.0 KW 13.0 amps
12V electrical system
(Extra low voltage)
Your caravan is fitted with a Power
Distribution Unit (PDU). This comprises
of the 230 volt RCD and MCB’s, Relay
housing and Power Supply/Battery
charger, this is located under the front
o side seat towards the centre of the
caravan.
