EDGE Installation Manual
www.cobantech.com Page 11 of 40
Cables and Extensions - Details
All Cables and Extensions running between Components are color coded at the plug for easy identification.
Black – CPU to LCD
Blue – CPU to Optional 2nd Detached Camera
Green – CPU to Primary Camera
Red – CPU to Receiver
