EDGE Installation Manual
www.cobantech.com Page 29 of 40
2012 Chevy Caprice Monitor Installation
The camera mount installation procedure described in the following steps was captured during the installation of the
EDGE system in an overhead/visor orientation in a Chevy Caprice. Different installation procedures will need to be
followed for installation of the EDGE system on other types of vehicles. For more information please contact COBAN
Technologies for more details on your specific vehicle type and orientation.
CAUTION: COBAN Technologies will not assume any responsibility or liability in the event that any type of damage
is caused to the windshield by a third party installer during the installation process.
1. Remove overhead dome light by pulling
down the front dome light assembly and
slide forward to release the two (2) latches.
2. Disconnect the cable to the dome light
To Next Page
