EDGE Installation Manual
www.cobantech.com Page 16 of 40
Front Camera Installation
The camera mount installation procedure described in the following steps was captured during the installation of the
EDGE system in an overhead/visor orientation in a Ford Crown Victoria. Different installation procedures will need to
be followed for installation of the EDGE system on other types of vehicles. For more information please contact
COBAN Technologies for more details on your specific vehicle type and orientation.
CAUTION: COBAN Technologies will not assume any responsibility or liability in the event that any type of damage is
caused to the windshield by a third party installer during the installation process.
Note:
1. Remove the screw from the passenger side Visor
Clip.
2. Use the passenger side Visor Clip to temporarily
secure the Camera Mount.
3. Secure the Camera Mount to the headliner with
the two (2) provided 1 ¼” self tapping screws.
