EDGE Installation Manual
www.cobantech.com Page 8 of 40
Wireless Microphone
Modulation
Mode
- Bi-directional digital spread spectrum
(DSS)
Frequency - 902 ~ 928MHz
Operating
Range
- 1000 ft
Battery - Rechargeable Li-Ion battery
Air Time - 8 ~ 10 hours of continuous operation
Standby Time - 14 ~ 16 days
Microphone - Integrated internal microphone
Channels - 20 channels with automatic
synchronization
Mobile Drive
Removable
Storage
- 40GB(Std)/80GB auto grade hard drive
32GB/64GB/128GB industrial grade
solid-state disk (optional)
Vibration - Random 10-2000 Hz 16.3G(X,Y,Z)
Shock 1,500G/0.5ms, 50G/ 11ms
Operating
Temperature
- -40°C ~ 85°C
Storage
Temperature
- -40°C ~ 100°C
Interface - USB 2.0
Physical
Dimensions
- 6” (W) x 5” (H) x 1.75” (D)
Capacity - MPEG1: 600MB/hr 352 X 240
MPEG2: 1.2GB/hr 704 X 480
MPEG4: 300-400 MB/hr
Wireless Microphone Receiver
EDGE Smart Power Unit ( SPU )
