COBHAM GR712RC Quick Start Guide

GR712RC-QSG
November 2018, Version 1.0
9 www.cobham.com/gaisler
APB: 80000E00 - 80000F00
IRQ: 14
satcan0 Aeroflex Gaisler SatCAN controller
AHB Master 4
AHB: FFF20000 - FFF20100
IRQ: 14
grspw0 Aeroflex Gaisler GRSPW2 SpaceWire Serial Link
AHB Master 5
APB: 80100800 - 80100900
IRQ: 22
Number of ports: 1
grspw1 Aeroflex Gaisler GRSPW2 SpaceWire Serial Link
AHB Master 6
APB: 80100900 - 80100A00
IRQ: 23
Number of ports: 1
grspw2 Aeroflex Gaisler GRSPW2 SpaceWire Serial Link
AHB Master 7
APB: 80100A00 - 80100B00
IRQ: 24
Number of ports: 1
grspw3 Aeroflex Gaisler GRSPW2 SpaceWire Serial Link
AHB Master 8
APB: 80100B00 - 80100C00
IRQ: 25
Number of ports: 1
grspw4 Aeroflex Gaisler GRSPW2 SpaceWire Serial Link
AHB Master 9
APB: 80100C00 - 80100D00
IRQ: 26
Number of ports: 1
grspw5 Aeroflex Gaisler GRSPW2 SpaceWire Serial Link
AHB Master 10
APB: 80100D00 - 80100E00
IRQ: 27
Number of ports: 1
b1553brm0 Aeroflex Gaisler AMBA Wrapper for Core1553BRM
AHB Master 11
AHB: FFF00000 - FFF01000
IRQ: 14
grtc0 Aeroflex Gaisler CCSDS Telecommand Decoder
AHB Master 12
AHB: FFF10000 - FFF10100
IRQ: 14
grtm0 Aeroflex Gaisler CCSDS Telemetry Encoder
AHB Master 13
APB: 80000B00 - 80000C00
IRQ: 29
adev14 Aeroflex Gaisler SLINK Master
AHB Master 14
APB: 80000800 - 80000900
IRQ: 13
mctrl0 Aeroflex Gaisler Memory controller with EDAC
AHB: 00000000 - 20000000
AHB: 20000000 - 40000000
AHB: 40000000 - 80000000
APB: 80000000 - 80000100
8-bit prom @ 0x00000000
32-bit static ram: 1 * 8192 kbyte @ 0x40000000
32-bit sdram: 2 * 128 Mbyte @ 0x60000000
col 10, cas 2, ref 7.8 us
apbmst0 Aeroflex Gaisler AHB/APB Bridge
AHB: 80000000 - 80100000
dsu0 Aeroflex Gaisler LEON3 Debug Support Unit
AHB: 90000000 - A0000000
AHB trace: 256 lines, 32-bit bus
CPU0: win 8, hwbp 2, itrace 256, V8 mul/div, srmmu, lddel 1, GRFPU
stack pointer 0x407ffff0
icache 4 * 4 kB, 32 B/line lru
dcache 4 * 4 kB, 16 B/line lru
CPU1: win 8, hwbp 2, itrace 256, V8 mul/div, srmmu, lddel 1, GRFPU
stack pointer 0x407ffff0
icache 4 * 4 kB, 32 B/line lru
dcache 4 * 4 kB, 16 B/line lru
apbmst1 Aeroflex Gaisler AHB/APB Bridge
AHB: 80100000 - 80200000
occan0 Aeroflex Gaisler OC CAN AHB interface
AHB: FFF30000 - FFF31000
IRQ: 5
cores: 2
ahbram0 Aeroflex Gaisler Generic FT AHB SRAM module
AHB: A0000000 - A0100000
APB: 80100000 - 80100100
