Chapter 2: Operation
10 Overview of the Radiotelex user interface
Overview of the Radiotelex user interface
When the system is powered, the Message Terminal display shows the main
menu and a status field. Below is an overview of the main screen in the
SAILOR MF/HF System 6000B Radiotelex.
• Time, UTC: The time of day, Universal Time Coordinated (received
from the GPS input of the MF/HF radio system).
• Name of current page: When you have entered a subpage, this field
shows the name of the page.
• Status field: This field shows a short status message next to the
Status/warning icon.
• Power status: Shows the status of the backup battery.
• Main menu items: Select these items to access the subpages.
Main menu items
Name of current page
Power status
Status field Status/alert iconTime, UTC
