Alerts and notifications
30 Chapter 3: Service & maintenance 98-137261-F
Rectified –
unacknowledged
alarm
A flashing red triangle. A tick mark in the
middle of the triangle.
This icon is displayed when the alarm
condition has been rectified but not yet
acknowledged.
Warning: Active
unacknowledged
alert
A flashing yellow circle with a symbol of a
loudspeaker in the middle of the circle. This
alert is accompanied by an audible warning
signal (2 beeps).
This icon is displayed when there is an active
unacknowledged warning.
Warning: Active
unacknowledged
alert, silent
A flashing yellow circle. A symbol of a
loudspeaker with a prominent diagonal line
through it.
This icon is displayed when there is an active
silenced warning.
Warning: Active
acknowledged alert
A yellow circle with an exclamation mark in
the middle of the circle.
This icon is displayed as long at the warning
condition is present.
Warning: Active
transferred alert
A yellow circle. An arrow pointing towards the
right in the middle of the circle.
This icon is displayed as long at the warning
condition is present.
Warning: Inactive
unacknowledged
alert, rectified
A flashing yellow circle with a tick mark in the
middle of the circle.
This icon is displayed when the warning
condition has been rectified but not yet
acknowledged.
